STANDARDS

FEATURES

MANAGEMENT FEATURES

•IEEE 802.3 10BASE-T
•IEEE 802.3u 100BASE-TX
•IEEE 802.ab 1000BASE-T
•IEEE 802.3z 1000BASE-SX/LX
•IEEE 802.3x Full-duplex and Flow Control
•IEEE 802.1x Port-based Network Access Control
•IEEE 802.1Q VLAN
•IEEE 802.3ad Link Aggregation
•IEEE 802.1d /w Spanning Tree Protocol
•IEEE 802.1p Class of Service, Priority Protocols
　

•RJ-45 Ports: 24
•SFP Slots: 4
•MAC Address: 8K
•Buffer Memory: 500K
•Jumbo Frames: 9.6K
•Transmission Method: Store and Forward
　

•LACP, RSTP
•MAC Filtering
•VLAN: Static VLAN: 256 up to 4K/Port-based VLAN/Tagged Based VLAN/Protocol-based VLAN
•Link Aggregation: LACP/Static Trunk/Traffic Load Balancing
- Max. 8 Group; Max. 8 Ports/Group
•IGMP Snooping V1/V2
•Trunk Groups: 8

QoS FEATURES

SECURITY

POWER REQUIREMENTS

•Priority Queue: 8 Queues/Port
•Rate Limit: Port-Based (Ingress/Egress)
•Queue Scheduling: WRR/WFQ/Strict Priority
•Class of Service: Port-based/Flow-based/802.1P

•IEEE 802.1X: Port-based/Guest VLAN
•Access Control List: MAC/IP/TCP/UDP
•Port Security
•Storm Control
•Port-based Many to One Mirroring

•100 to 240V AC, 50/60Hz

TEMPERATURE

DIMENSIONS & WEIGHT

CERTIFICATIONS

•Operating: 0 to 50℃
•Storage: -40 to 70℃
•Operating: 10 to 90% RH (Non-Condensing)

•19” & 1U Rack Mountable
•440 (W) x 44 (H) x 220 (D) mm

•CE
•FCC
