PC-6009
鉤式功率錶
簡介
- 交流瓦特 (AC)： 20 ~ 100kWatt ±3%
- 鉤式交流電流：0 ~ 600A ±2%
- 直流電壓：0V ~ 200V ±0.8%
- 交流電壓：0V ~ 600V ±1%
- 電阻：0 ~ 2000歐姆 ±1%
- 鉤部口徑37mm
- Size：230 X 74 X 38mm
FEATURES
- Watt ( true power ) , ACV , DCV , ACA , OHMS , Diode.
- Watt measurement via the inductive clamp jaw.
- Wide range for power measurement, max.
- value up Design meet IEC 1010 safety requirement.
- Heavy duty ACA clamp meter, 600 A max. range.
- Compact & heavy duty ABS housing plastic case.
- Measure AC current by the inductive conductor.
- LSI circuit provides high reliability and durability.
- LCD display, clear readout Overload protection circuit is provided for all range.
一般規格
顯示 (Display)
- 13 mm ( 0.5" ) LCD , 3 1/2 digits. Max. indication 1999.
測量 (Measurement)
- Watt (true power) . DCV , ACV , ACA , ohms , Diode.
極性 (Polarity)
- Automatic Switching, ' － ' indicates negative polarity.
電流感應器 (Current Sensor)
- Hall effect sensors.
輸入過載指示 (Over-input indicator)
- display shows ' 1 ' or ' -1 '.
功率歸零調整 (Watt Zero Adjustment)
- Built-in external adjustment knob.
取樣時間 (Sampling Time)
- Approx. 0.4 second.
電池 (Battery)
- Heavy duty type or Alkaline battery. DC 9V battery. 006P, MN1604 ( PP3 ) or equivalent.
操作溫度 (Operating Temp.)
- 0 ℃ to 50 ℃ (32 ℉ to 122 ℉).
操作溼度 (Operating Humidity)
- Less than 80% RH.
電源供應 (Power Supply)
- 006P DC 9V battery ( heavy duty type ).
電源消耗 (Power Consumption)
- Approx. DC 15 mA.
體積 (Dimensions)
- HWD 230 x 74 x 38 mm. ( 9.1 x 2.9 x 1.5 inch )
重量 (Weight)
- 480 g/0.88 LB ( including battery ).
主體尺寸 (Conductor Size)
- 73.5 mm ( 2.9 inch ) - out side.
附件 (Accessories Included)
- Red and Black Test Leads ..... 1 pair.
- Instruction Manual ........... 1 PC.
選購附件及轉換器
- Carry case : CA-05A
電器規格 (23±5 ℃)
| Function |
Range |
Resolution |
Accuracy |
Overload Protection |
| AC Watt (true power) * ref. remark |
20 KW |
0.01 KW |
± ( 3% + 8d ) |
Volt input : AC 600V Current input : AC 500A |
| 100 KW |
0.1 KW |
± ( 3% + 5d ) |
| DC voltage |
200 V |
0.1 V |
± (0.8 % + 1 d ) |
DC 600 V. |
| AC voltage |
600 V |
1 V |
± (1% + 2 d) |
AC 600 V. |
| OHMS |
2 k ohm |
1 ohm |
± (1 % + 1 d) |
AC/DC 250 V |
| AC current |
200 A |
0.1 A |
± (2% + 10 d) |
1000 ACA |
| 600 A |
1 A |
± (2% + 5 d) |
Diode
- Short/non conductance, good/defect test
Continuity Beeper
- A continuity testing beeper is equipped, so when checking circuits of shorts or opens, then it is not necessary to look at the meter.
- The Beeper sounds will be generated if continuity is present.
|
