GB-150KG
數字計重秤
特色
- 秤量範圍 : GB-150KG : 0.3 ~ 150.0公斤
- 解析度 : GB-150KG/0.1公斤
- 精確度 : ±0.5%
- 具有扣重'歸零功能
- 公斤/磅單位選擇切換
- 秤盤尺寸 : 45 x 34公分
- 顯示器尺寸 : 18.8 x 6.5 x 3.7公分
FEATURES
150 Kg heavy duty digital bench parcel scale.
Separate indicator, easy to weight the large object on the platform.
Microcomputer circuit with high accuracy & better performance.
High resolution & wide measuring capacity
Platform use the stainless material.
14.2 mm ( 0.56" ) digit size red LED display, easy read out.
Built-in Kg & LB unit adjustment, select by the internal slide switch.
規格
顯示 (Display)
- Red LED, 4 digits, 14.2 mm ( 0.56" ) digit size.
測量容量 (Measuring Capacity)
- 150 Kg/330 LB.
解析度 (Resolution)
- 0.1 Kg/0.2 LB.
最低顯示重量 (Min. Display Weight)
- 0.3 Kg/0.6 LB.
單位選擇 (Unit select)
- Kg or LB ( internal select ).
精確度 (Accuracy)
- ± ( 0.5 % + 2 d ). * Specification test under 90% full scale.
取樣時間 (Sampling time)
- Approx. 0.8 second.
過載容量 (Overload capacity)
- Max. 200 Kg.
容器重量控制 (Tare Control)
- Full capacity.
轉換器 (Transducer)
- Load cell.
電路 (Circuit)
- Exclusive LSI-circuit.
操作溫度 (Operating Temp. )
- 0 to 50 ℃. (32 to 122 ℉ ).
操作溼度 (Operating Humidity)
- Less than 80% R.H.
尺寸 (Size)
- Cabinet : 18.8 x 6.5 x 3.7 cm ( 7.4 x 2.6 x 1.4 inch ).
- Platform: 45 x 34 cm ( 17.7 x 13.3 inch ).
重量 (Weight)
- 10.4 Kg ( 22.9 LB ). * Indicator + Platform + batteries.
包裝尺寸 (Packing size)
- Carton box, 67 x 47 x 26 cm ( 26.3 x 18.5 x 10.2 inch ).
包裝重量 (Packing weight)
- 13.2 Kg ( 29.1 LB ).
電源供應 (Power Supply)
- 6 x 1.5V AA (UM-3) batteries, or DC 9V adapter.(not included).
電源損耗 (Power Consumption)
- Approx. DC 81 mA
附件 (Standard Accessory)
- Operating manual .................... 1 PC.
選購附件 (Optional Accessories)
- * AC to DC adapter ( 500 mA ).
|
