TFG3610E
數位任意波信號產生器
1uHz~10MHz 雙通道
功能特點
- 最大頻率輸出10MHz
- 3.5英寸彩色 LCD顯示
- 採用先進DDS技術
- 採樣率100Msa/s，垂直解析度8位，波形記憶長度1Kpts
- 具有任意波功能，可設置8組用戶自定義波型
- 可輸出32種內建波形和8組用戶自定義波形
- 40組面板設定存儲及呼叫
- 最小輸出1mV (50Ω) 穩定波形
- FM， FSK，ASK，PSK多種調製功能
- 頻率掃描、觸發、TTL輸出
- 多重保護功能:過電壓、過電流、短路保護、反灌電壓保護功能
- 標配:RS-232介面，200MHz內建頻率計
產品描述
- TFG-3600E系列函數/任意波形產生器採用直接數位合成技術（DDS），具有快速完成測量工作所需的高性能指標和眾多的功能特性。
- 簡單且功能明晰的前面板設計和中/英文液晶顯示介面能使您更便於操作和觀察
- 擴展的選件功能，可使您獲得增強的系統特性
規格
Model：TFG-3610E
Frequency range：1μHz~10MHz
Waveform (Output A)
Types
- 32 built-in waveforms, including Sine, Square, Triangle,Ramp,Pulse,etc.
- And 8 user- defined arbitrary waveforms
Length
- 1024 points
Vertical resolution
- 8 bits
Sampling rate
- 100MSa/s
Harmonic distortion
- ≥40dBc(<1MHz); ≥35dBc (1~20MHz)
Total distortion
- ≤1% (20Hz~200kHz)
Rise/fall time of square
- ≤35ns, Overshoot: ≤10%
Duty cycle of square
- 1%~99%
Frequency (CHA)
Range
- Sine：1uHz~10MHz
- Squre：1uHz~5MHz
- Other：1uHz~1MHz
Resolution
- 1uHz
Accuracy
- ± (50ppm + 40mHz)
Amplitude (Output A)
Range
- 2mVpp~20Vpp, 1uHz~10MHz (high impedance)
- 2mVpp~15Vpp, 10MHz~15MHz (high impedance)
- 2mVpp~8Vpp, 15MHz~20MHz (high impedance)
Resolution
- 20mVpp (amplitude>2Vpp), 2mVpp (amplitude<2Vpp)
Accuracy
- ± (1% +2 mVrms) (high impedance, RMS, frequency 1kHz)
Stability
- ±0.5% / 3 hours
Flatness
- ±5% (frequency±10% (frequency> 10MHz)
Output impedance
- 50Ω
DC Offset (CHA)
Range
- ±10V (high impedance, attenuation 0 dB)
Resolution
- 20mVdc
Accuracy
- ±(1% + 20mVdc)
Sweep (CHA)
Parameter
- Frequency,Amplitude
Range
- Free to set starting point and end point
Time
- 100ms~900s
Direction
- Up,Down,Up-Down
Mode
- Linear, Logarithmic
Control
- Auto sweep or manual sweep
Frequency Modulation (FM) (CHA)
Carrier signal
- CHA Signal
Modulating signal
- CHB or external signal
FM deviation
- 0%~20%
Burst(CHA)
Carrier signal
- CHA Signal
Trigger signal
- TTL_A Signal
Burst counts
- 1~65000 cycles
Trigger mode
- Interna TTLl, External, Signle
Shift keying(CHA)
FSK
- Free to set the hop frequency and carrier frequency
ASK
- Free to set the hop amplitude and thecarrier amplitude
PSK
- Hop phase: 0~360°, resolution: 1°
Alternative rate
- 10ms~60s
Waveform(CHB)
Type
- 32 built-in waveforms, including Sine, Square, Triangle,Ramp,Pulse,etc. And 8 user- defined arbitrary waveforms
Length
- 1024 points
Vertical resolution
- 8 bits
Sampling rate
- 12.5Msa/s
Duty cycle of square
- 1%~99%
Frequency(CHB)
- 40mHz~1MHz
- Other waveforms: 10mHz~100kHz
Range
- Sine:1uHz~1MHz
- Other:1uHz~100KHz
Resolution
- 1uHz
Accuracy
- ± 1x10^-5
Amplitude(CHB)
Range
- 50mVpp~20Vpp (high impedance)
Resolution
- 20mVpp
Output impedance
- 50Ω
Burst(CHB)
- 1~65000 cycles
Carrier signal
- CHB Single
Trigger signal
- TTL_B Signal
Burst counts
- 1~65000 cycles
Tigger mode
- Interna TTLl, External, Signle
TTL output
Waveform
- Square wave, rise/fall time ≤20ns
Frequency
- 10mHz~1MHz
Amplitude
- TTL , CMOS compatible, low<0.3V,high>4V
Frequency counter
Testing frequency range
- 1Hz~200MHz
Input signal amplitude
- 100mVpp~20Vpp
Remote counter
- RS-232 interface
General
Operation characteristics
- Key operation for all funcations,Menu display,Rotary dial adjustment
Display
- TFT LCD
Language
- English,Chinese(simplified),Chinese(traditional)
Power consumption
- AC110V/220V±10% selectable,50/60Hz,Max.45VA
Environmental
- Temperature 0~40℃,<80%RH
Standard accessories
- Power cord×1,Operation manual×1,Software CD×1,RS-232 cable×1,BNC-BNC cable×1,Test lead×1
Dimension
- 385×260×110mm
Weight
- 3.5Kg
|
