DI-6200
絕緣阻抗測試器
(停產)
特色
- 測量範圍：
- 絕緣阻抗：
- 200M歐姆 / 500V ±3%
- 1000M歐姆 / 1000V ±3%
- 電阻：
- 0.1 ~ 200歐姆 ±1%
- 內建過載保護裝置及電力不足指示功能
- 採用大型液晶顯示器，容易讀取
- Size：170 X 127 X 78mm
FEATURES
- Digital display, easy and correct read-out.
- Multi Mega ohm range with 0-200 Mega ohm at 500 V DC, 0-1000 Mega ohm at 1000 V DC.
- Build in precision 200 ohm range easy for measuring low resistance such as motor windings, relay coils etc.
- 18 mm (0.7") large LCD display.
- Battery operating easily to carry with user.
- LCD display allows clear read-out even at bright place.
- LSI-circuit provides high reliability and durability.
- Built-in over-input and low battery indication.
- Overload protection for each range.
- Automatic zero adjust.
- Durable & portable housing case with handle.
一般規格
顯示 (Display)
- 18 mm (0.7") LCD ( Liquid Crystal Display ), Max. indication 1999.
測量 (Measurement)
- Insulation :
- 200M ohm/500V
- 1000M ohm/1000V
- OHMS :
- 200 ohm
取樣時間 (Sampling Time)
- 0.4 second.
百萬歐姆反應時間 (Mega ohm Respond Time)
- Max. approx. 2.5 second.
歸零調整 (Zero Adjustment)
- Automatic adjustment.
過載輸入顯示 (Over-input)
- Indication of "1" .
操作溫度 (Operating Temp.)
- 0 ℃ to 50℃ ( 32 ℉ to 122 ℉ ).
操作溼度 (Operating Humidity)
- Less than 80 % R.H..
電源供應 (Power Supply)
- DC 9V, 1.5V AA(UM-3) battery x 8 PCs. Alkaline or heavy duty battery.
電源損耗 (Power Consumption)
- Approx. 100 mA (1000M ohm/1000V range).
- Approx. 50 mA (200 M ohm/500V range).
- Approx. 1.6 mA (200 ohm/OHMS range).
體積 (Dimension)
- 170 x 127 x 78 mm (6.7 x 5.0 x 3.1 inch), with housing front cover.
重量 (Weight)
- 560 g (1.2 LB).
附件 (Standard Accessories)
- Instruction Manual .................1 PC
- Alligator Clips, AL-03.............1 pair
電氣規格 (ELECTRICAL SPECIFICATIONS) 23±5 ℃
百萬歐姆
(Mega ohm)
| Range |
Accuracy |
Resolution |
Circuit voltage |
| 200 Mega ohm ( 500V ) |
± (3% + 1d) |
0.1 M ohm |
Approx.DC 480 V (over 8M ohm) |
| 1000 Mega ohm ( 1000V ) |
± (3% + 1d) |
1 M ohm |
Approx. DC 975 V (over 8M ohm) |
- * Input terminal Short circuit current is approx. 0.2 mA. for 200 M OHM/500 V range.
- * Input terminal Short circuit current is approx. 0.2 mA. for 1000 M OHM/1000 V range.
歐姆 (ohm)
| Range |
Accuracy |
Resolution |
Circuit voltage |
| 200 ohm |
± (1% + 1d) |
0.1 ohm |
Approx. 3 V |
- * Overload Circuit Protection AC/DC 500V (within 20 sec)
|
