Switch Properties |
Back-plane (Switching Fabric):
5.6Gbps Packet
throughput ability (Full-Duplex): 1488096pps
@64bytes |
Transfer Rate |
14,881pps for Ethernet port
148,810pps for Fast Ethernet port
148,8100pps for Gigabit Ethernet port |
Connectors |
10/100/1000TX: 8 x RJ-45 with
auto MDI/MDI-X
function
1000M fiber: 2 x GIGA SFP slot for Single-mode
or
Multi-mode type fiber cable |
MAC Address |
16K MAC addresses |
Packet Buffer |
4M bits |
Processing |
Store-and-Forward |
Network Cable |
10Base-T: 2-pair UTP/STP Cat. 3,
4, 5, 6 cable
EIA/TIA-568 100-ohm (100m)
100Base-TX: 2-pair UTP/STP Cat. 5, 6 cable
EIA/TIA-568 100-ohm (100m) |
Optical Cable |
Multi-mode: 50/125um~62.5/125um
Single-mode: 9/125um
Available distance: 2km (Multi-mode)/30km (Singlemode)
Wavelength: 1310nm (Multi-mode/Single-mode) |
Protocol |
CSMA/CD |
Case Dimension |
Metal case,IP-30;
167mm(W)x67mm(D)x48mm(H) |
Weight |
480g |
LED |
Power Indicator
Green LED x 2
10/100/1000Base-T(X) RJ45 port indicator
Green for port Link/Act. Amber for
Duplex/Collision |
Power Supply |
48~54VDC, Redundant power with
polarity reverse
protect function and removable terminal block |
Consumption |
8.76 Watts (Full load: Only
Ethernet) |
Overload Current |
Present |
Reserve Polarity |
Present |
Operating
Humidity |
5% to 95% Non-condensing |
Operating
Temperature |
-20°C~60°C |
Storage
Temperature |
-40°C~85°C / -40°F~185°F |
MTBF |
Over 190000 hours ,( >20 Years) |
FCC(EMI) |
FCC Part15,SubpartB ,Class A |
CE(EMi) |
EN61000-6-4(EMI) |
CE(EMS) |
EN61000-4-2 (ESD),
EN61000-4-3 (RS),
EN61000-4-4 (EFT),
EN61000-4-5 (Surge),
EN61000-4-6 (CS),
EN61000-4-8,
EN61000-4-11
EN61000-6-2(EMS) |
Stability Testing |
IEC60068-2-31 (Drop Off)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration) |
Warranty |
3 years |
