TM-909AL
紅外線溫度計
(停產)
特色
- 測量範圍 :
- IR:-20 ~ 400°C (-4~752°F) ±3%
- Type K:-100 ~ 1300°C (-148~2372°F) ±1%
- 放射率設定 : 0.20 ~ 1.00
- 攝氏(°C) / 華氏(°F)單位選擇
- 距離與量測點比(D:S)=7:1
- 可記錄最大值'最小值及讀值鎖定
- 具有雷射瞄準光點
- Size:195 X 120 X 58mm
FEATURES
- 2 in 1, Infrared thermometer + Type K thermometer.
- Infrared thermometer, non-contact temperature measurement, -20 ℃ to 400 ℃ ( -4 ℉ to 752 ℉ ).
- Microcomputer circuit with high performance.
- Wide temperature measuring range.
- 0.1 ℃ display resolution both for the measurement of IR thermometer and Type K thermometer.
- Build in ℃ & ℉ select button on the front panel.
- Data hold function.
- Memory function to record the maximum & minimum reading with recall.
- Build the REL button, useful for relative measurement.
- Sensor select button on the front panel, easy to change different type probe.
- Emissivity adjustment for IR thermometer.
- Red laser target light guide for IR thermometer.
- RS 232 data output, easy cooperate with computer.
- Optional data acquisition software for data record.
- Auto power shut off saves battery life.
- Built-in low battery indicator.
- Heavy duty & compact housing case with stand.
- Operates from 006P DC 9V battery.
一般規格
顯示 (Display)
- Dual display with annunciator :
- * Main display : 10 mm (0.4") LCD, 5 digit.
- * Small display : To show the emissivity value.
感應器型式 (Sensor Type)
- 1. Infrared thermometer ( Non contact temperature measurement )
- 2. Type K thermometer
功能 (Functions)
- ℃, ℉, Data hold, Memory ( Max., Min. ), Relative measurement, Emissivity adjustment (IR thermometer).
解析度 (Resolution)
- 0.1 degree.
電路 (Circuit)
- Exclusive microcomputer circuit, the software build in linearity correction instead the traditional hardware circuit.
放射率調整 (Emissivity Adjustment)
- Range : 0.20 to 1.00. Adjustment by pushing button on front panel.
光源 (Target Guide)
- Red color, laser power less than 1 mW.
感溫棒輸入接頭 (Probe Input Socket)
- Standard 2 pin thermocouple socket.
取樣時間 (Sampling Time)
- Approx. 1 second.
鎖定功能 (Hold Function)
- To freeze the display reading value.
記憶回叫 (Memory Recall)
- Memorize the Maximum, Minimum reading with recall.
差距值調整 (Offset Adjustment)
- Available for thermocouple thermometer offset adjustment by pushing button on front panel.
過載指示 (Over Indication)
- Show " - - - - ".
資料輸出 (Data Output)
- RS232 PC serial interface.
電源供應 (Power Supply)
- Alkaline or heavy duty type, DC 9V battery, 006P, MN1604 ( PP3 ) or equivalent.
電源損耗 (Power Consumption)
- Approx. DC 12 mA ( w/o tagret light on ).
- Approx. DC 23 mA ( with target light on ).
- * Above consumption value is calculated under the function of IR thermometer.
操作溫度 (Operating Temp. )
- 0 to 50 ℃ (32 to 122 ℉).
操作溼度 (Operating Humidity)
- Less than 80% RH.
重量 (Weight)
- 260 g/0.57 LB.
體積 (Dimension)
- 195 x 120 x 57 mm. ( 7.7 x 4.7 x 2.2 inch).
附件 (Standard Accessory)
- Operational manual..... 1 PC.
選購附件 (Optional Accessory)
- Hard carrying case ; Model
: CA-06
- USB cable ; Model : USB-01
- RS232 cable ; Model : UPCB-02
- Type K thermocouple probe. ; TP-01, TP-02A. TP-03, TP-04
- Data acquisition software ; Model : SW-U801-WIN
電氣規格 ELECTRICAL SPECIFICATIONS (23 ±5 ℃)
紅外線熱電偶 (Infrared Thermometer)
解析度/範圍 (Resolution/ranges)
- 0.1℃ : - 20 ℃ to 400 ℃
- 0.1℉ : -4 ℉ to 752 ℉
精確度 (Accuracy)
- ± 3 % of reading or ± 3 ℃( 5 ℉), which ever is greater.
- * Accuracy test under the measurement range within - 10 ℃ to 350 ℃
- * Meter operating temp. within 23± 5 ℃ and the emissivity value of measurement target set to 0.95.
- * Spec. tested under the 20 cm dia. black body, the measuring distance from the probe sensing Head is 30 cm.
溫度感應器 (Temp. Sensor)
- Thermocouple pie.
放射率設定 (Emissivity Setting)
- * By push button. Setting range : 0.20 to 1.00.
- * The default emissivity value is 0.95, which will cover 90% of a typical application.
測量波長區域 (Measurement Wave length Region)
- 6 to 12 micro meter.
距離因素 (Distance Factor)
- D/S : Approx. 7:1. (D - Distance, S - Spot.)
K TYPE 熱電偶 (Type K Thermometer)
Sensor Type |
Resolution |
Range |
Accuracy |
Type K |
0.1 ℃ |
-100.0 to 1300.0 ℃ |
± ( 1 % + 1 ℃ ) |
0.1 ℉ |
-148.0 to 2372.0 ℉ |
± ( 1 % + 2 ℉ ) |
- Remark :
- a. Accuracy value is specified for the meter only.
- b. Accuracy test is based on the environment temperature of 23 ± 5℃.
- c. Linearity Correction : Memorize the thermocouple's curve into the CPU circuit.
|
