YK-2005TM
記憶式溫度計
(停產)
特色
- 記錄16000筆資料 , 含時間記錄 (年月日時分秒)
- 測量範圍 :
- TYPE K : -50.0 ~ 1300.0°C ±0.2%
- TYPE J : -100.0 ~ 1100.0°C ±0.2%
- PT-100 : -200 ~ 850.0°C ±0.2%
- 紅外線測溫棒: -10 ~ 300°C ±0.3%
- 測溫棒及紅外線測溫棒皆為選購品
- 讀值鎖定及記錄測量中之最大 / 最小值
- RS-232 / USB 連接介面(軟體選購)
- Size：203 X 76 X 38mm
FEATURES
- 3 in 1, Thermocouple ( Type K/J ) thermometer, Pt 100 ohm thermometer + Infrared thermometer.
- 0.1 degree resolution for Pt 100 ohm & type K/J.
- Wide temperature measuring range.
- 4 wires PT 100 ohm probe input, 0.00385 alpha coefficient, meet DIN IEC 751, high precision.
- Offset adjustment.
- Fast humidity measuring response time.
- Real time data logger, build in clock ( hour-min.-sec., year-month-date ).
- Auto data record, 16,000 Data logger no.
- Wide sampling time adjustment range from two seconds to 8 hours 59 minutes 59 seconds.
- RS232 computer interface.
- Can default auto power off or manual power off.
- Multi function with easy operation
- Large LCD with multiple display.
- Data hold, record max. and min. reading.
- Microcomputer circuit provides special function & offer high accuracy.
- Power by UM3 ( 1.5 V ) x 4 batteries or DC 9V adapter.
- RS232 PC serial interface.
- Separate probe, easy for operation of different measurement environment.
一般規格
電路 (Circuit)
- Custom one-chip of microprocessor LSI circuit.
顯示 (Display)
- LCD size : 58 mm x 34 mm.
測量 (Measurement)
- 1. Thermocouple probe
- @ Thermocouple type K
- @ Thermocouple type J
- 2. Platinum Pt 100 ohm ( 0.00385 alpha coefficient, meet DIN IEC 751 )
- 3. Infrared Thermometer
顯示單位 (Display Unit)
- ℃, ℉.
解析度 (Resolution)
- 0.1 ℃, 0.1 ℉.
資料集錄器取樣時間 (Sampling Time of Data Logger)
- 2 sec to 8 hour 59 min. 59 sec. @ Auto datalogger
溫度補償 (Temperature Compensation)
- Automatic temp. compensation for the cold junction both type K/J thermometer and Infrared Thermometer.
線性補償 (Linear Compensation)
- Both for Type K/J. Pt 100 ohm and the IR thermometer.
差距值,取值調整 (Offset, Span Adjustment)
- Available to adjust the zero drift value, adjustment by pushing button.
感測器輸入接頭 (Probe Input Socket)
- Type K, Type J :
2 pin thermocouple socket.
- Pt 100 ohm : Ear phone socket.
過載指示 (Over Indication)
- Show of "- - - -".
資料鎖定 (Data Hold)
- Freeze the display reading.
記憶回叫 (Memory
Recall)
- Memorize the Maximum, Minimum reading with recall.
顯示之取樣時間 (Sampling Time of display)
- Approx. 1 second.
電源關機 (Power off)
- Auto shut off saves battery life. or manual off by push button.
資料輸出 (Data Output)
- RS232 PC serial interface.
操作溫度 (Operating Temp. )
- 0 to 50 ℃ (32 to 122 ℉).
操作溼度 (Operating Humidity)
- Less than 80% RH.
電源供應 (Power Supply)
- DC 1,5 V battery ( UM3 ) x 4 PCs, ( Heavy duty type ).
- DC 9V adapter input. * AC/DC power adapter is optional.
電源電流 (PowerCurrent)
- Approx. DC 21.5 mA
- @ Main instrument.+ Type K/J ( Pt 100 ) probe
重量 (Weight)
- 515 g/ 1.13 LB. @ Battery is included.
體積 (Dimension)
- 203 x 76 x 38 mm
附件 (Standard Accessory)
- Instruction manual.....................1 PC.
- Type K probe, TP-01....................1 PC.
- Carrying case..........................1 PC
選購附件 (Optional & accessories Temp. Probe)
- * Type K thermocouple probe. TP-02A. TP-03, TP-04
- * Pt 100 ohm probe, PT-100P
- * Infrared Probe, YK-200PIR
- * AC to DC 9V adapter.
- * RS232 cable/UPCB-02, USB cable/USB-01
- * Data Acquisition software, SW-U801-WIN.
- * Data Logger software, SW-DL2005.
電氣規格 ELECTRICAL SPECIFICATIONS (23± 5 ℃)
K/J 型式熱電偶 (Type K/J thermometer)
| Sensor Type |
Resolution |
Range |
Accuracy |
| Type K |
0.1 ℃ |
-50.0 to 1300.0 ℃ |
± ( 0.2 % + 0.5 ℃ ) |
| -50.1 to -100.0 ℃ |
± ( 0.2 % + 1 ℃ ) |
| 0.1 ℉ |
-58.0 to 2372.0 ℉ |
± ( 0.2 % + 1 ℉ ) |
| -58.1 to -148.0 ℉ |
± ( 0.2 % + 1.8 ℉ ) |
| Type J |
0.1 ℃ |
-100.0 to 1100.0 ℃ |
± ( 0.2 % + 0.5 ℃ ) |
| -50.1 to -100.0 ℃ |
± ( 0.2 % + 1 ℃ ) |
| 0.1 ℉ |
-58.0 to 2012.0 ℉ |
± ( 0.2 % + 1 ℉ ) |
| -58.1 to -148.0 ℉ |
± ( 0.2 % + 1.8 ℉ ) |
- * Accuracy value is specified for the meter only.
- * Type K probe, TP-01 is the standard accessory.
- * Other Type K probe. TP-02A, TP-03. TP-04 is the optional accessories.
白金 PT 100 歐姆 熱電偶 (Platinum PT 100 ohm Thermometer)
| Resolution |
Range |
Accuracy |
| 0.1 ℃ |
-200.0 to 850.0 ℃ |
± ( 0.2 % + 0.5 ℃ ) |
| 0.1 ℉ |
-328.0 to 1562.0 ℉ |
± ( 0.2 % + 1.0 ℉ ) |
Remark :
- a. Accuracy value is specified for the meter only.
- b. Linearity Correction : Memorize the Pt 100 ohm's curve into the intelligent CPU circuit.
- c. Pt 100 probe input, 0.00385 alpha coefficient, meet DIN IEC 751.
- d. 4 wires Pt 100 ohm probe ( Model : PT-100P ) is optional.
紅外線熱電偶 (Infrared Thermometer)
測量範圍 (Measurement Range)
- -10 ℃ to 300 ℃ / 14 ℉ to 572 ℉.
解析度/ 精確度 (Resolution/ Accuracy)
- 1℃ or 1℉.
- ± 3 % of reading or ± 3℃ which ever is greater.
- * It should cooperate the optional IR probe, YK-200PIR.
- * Meter operating Temp. within 23± 5℃ & the emissivity value of measurement target is 0.95.
- * Spec. tested under the 20 cm dia. black body, the measuring distance from the Probe sensing Head is 30 cm.
|
