CM-9930R
多功能交直流鉤錶
簡介
- 交直流電壓：0.001V ~ 1000V ±1%
- 交直流電流：0.1A ~ 2000A ±2%
- 電阻：0.1 ~ 40M歐姆 ±1%
- 電容：10pF ~ 50uF ±3%
- 頻率：0.01Hz ~ 100KHz ±1%
- 真均方根值 ( True RMS ) 讀取，自動換檔
- 鉤部口徑60mm
- DCA按鍵式歸零，背光顯示功能
- CM-9930R RS-232/USB連接介面 (軟體選購)
- Size：255 X 73 X 38mm
FEATURES
- 2in1, 2000A clamp meter + Digital multimeter.
- Meet IEC 1010 CATIII 1000V safety requirement.
- True rms reading for ACV & ACA measurement.
- 4000 counts, Auto range, multi-functions for ACA , DCA , ACV , DCV , Ohms , Capacitance , Hz , Diode , Duty cycle and continuity check.
- LSI circuit provides high reliability and durability.
- Wide ranges ( 2000A, 400 A ) clamp on current measurement both for ACA & DCA.
- 4 ranges ( 400 uA , 4000 uA , 40 mA , 400 mA ) direct current input measurement both for ACA & DCA.
- Overload protection circuit is provided for all ranges.
- Data hold, Relative key, Back light.
- RS232/USB PC COMPUTER interface.
- Compact & heavy duty ABS and fireproof plastic case.
一般規格
顯示 (Display)
- 15 mm (0.6") LCD, 4 digits, Max. indication 5000 ( frequency range ).
測量範圍 (Measurement Range)
- ACA, DCA, ACV, DCV, Ohms, Diode, Hz, Capacitance, Duty cycle, Continuity beeper.
極性 (Polarity)
- Automatic Switching, ' － ' indicates negative polarity.
電流感應器 (Current Sensor)
- Hall effect sensors.
歸零調整 (Zero Adjustment)
- DCA : Push bottom adjustment.
- Other ranges : Automatic adjustment.
輸入過載指示 (Over-input indicator)
- Indication of " oL " or " -oL ".
取樣時間 (Sampling Time)
- Approx. 0.35 second.
電池 (Battery)
- DC 9V battery, heavy duty or Alkaline type, 006P, MN1604 ( PP3) or equivalent.
電源消耗 (Power Consumption)
- Approx. DC 5 mA.
操作溫度 (Operating Temp.)
- 0 ℃ to 50 ℃ ( 32 ℉ to 122 ℉ ).
操作溼度 (Operating Humidity)
- Less than 80% RH.
重量 (Weight)
- 380 g/0.85 LB ( including battery ).
體積 (Dimensions)
- HWD 255 x 73 x 38 mm. ( 10 x 2.9 x 1.5 inch )
鉤部口徑 (Max. Jaw Open Size)
- 51 mm ( 2.1 inch ) Dia.
附件 (Accessories Included)
- Red and Black Test Leads ............ 1 pair.
- Fuse ( 500 mA, 5 mm dia. x 20 mm ) ...1 PC
- Instruction Manual .................. 1 PC.
選購附件及轉換器 (Optional Carrying case & Adapters)
- RS232 cable.................... UPCB-02
- USB cable...................... USB-01
- Data Acquisition software ......SW-U801-WIN
- Carrying case,
- EMF Adapter,
- Light Adapter,
- Anemometer Adapter,
- Pressure Adapter,
- Sound Adapter,
- Tachometer Adapter,
- High Voltage Probe.
電器規格 (23±5 ℃)
| Function |
Range |
Resolution |
Accuracy |
Overload Protection |
| DC/AC Voltage |
400 mV (DC only) |
0.1 mV |
± ( 0.5 % + 2d ) |
AC/DC 1000 V. |
| 4 V |
0.001V |
DCV: ± ( 1 % + 2d ) ACV:± ( 1.2 % + 5d ) |
| 40 V |
0.01V |
| 400 V |
0.1 V |
| 1000V |
1 V |
| DC / AC Current (Direct input) |
400 uA |
0.1 uA |
± ( 1.2% + 5d ) |
AC/DC 500 mA ( Fuse ) |
| 4000 uA |
1 uA |
| 40 mA |
0.01 mA |
| 400 mA |
0.1 mA |
| DC /AC current (Clamp on) |
400 A |
0.1 A |
± ( 2 % + 5 d ) |
AC/DC 2000A/1000V |
| 2000 A |
1 A |
± ( 2 % + 8 d ) |
Remark |
- * True rms measurement both for ACV, ACA function.
- * Input impedance for ACV & DCV range is 10 Mega ohm.
- * ACA, ACV frequency response is from 45 to 1 KHz.
- * ACA, ACV specification be tested on sine wave 50/60 Hz.
|
| Ohms |
0.1 ohm |
± ( 1 % + 5 d ) |
AC / DC 400V |
| 4 K ohm |
1 ohm |
| 40 K ohm |
10 ohm |
| 400 K ohm |
100 ohm |
| 4 M ohm |
1 K ohm |
± ( 2 % + 2 d ) |
| 40 M ohm |
10Kohm |
± ( 3.5 % + 5d ) |
| Capacitance |
50 nF |
10 pF |
± ( 3 % + 5d ) * See Remark |
AC / DC 400V |
| 500 nF |
100 pF |
| 5 uF |
0.001 uF |
| 50 uF |
0.01 uF |
| Frequency ( > 5 V ) |
5 Hz |
0.001 Hz |
± (1 % + 5 d) |
AC / DC 1000V |
| 50 Hz |
0.01 Hz |
| 500 Hz |
0.1 Hz |
| 5 KHz |
1 Hz |
| 50 KHz |
0.01 KHz |
| 100 KHz |
0.1 KHz |
|
Duty cycle |
1 % to 99 % |
0.1 % |
|
Diode |
Short/non conductance, good/defect test |
| Continuity |
If rmeasuring esistance is less than 10 ohm, the beeper will sound . |
|
