RBOX-408 電阻箱
特色
- 提供確實可信賴的電阻值
- 採小型化 ，易於攜帶
- 1~11111110 歐姆，提供寬範圍的電阻值
- 採滑動開關設計，可用開關增減電阻值
- 精確度：± 1%
- Size：147 X 117 X 47mm
FEATURES
- Applications :
- General applications
- Troubleshooting
- maintenance
- Education and Vocational training
- Production line testing
- Radio and TV services
- Working standards
- Research design & develop
- Physics laboratory work Pocket size
- offering accurate
- reliable performance.
- 1 to 11,111,110 ohm, wide range and high resolution ( 1 ohm per step ), practical and versatile tools.
- With seven decades of resistance.
- Slide switches that allow the user to simply add or subtract for desired value.
- Terminals with multi way binding posts, one to switch shield case.
規格
範圍
(Range)
- 1 to 11,111, 110 ohm ( 1 ohm per step )
精確度 (Accuracy)
- 1 W.
- * Do not add the voltage over AC/DC 250 V to the output resistance terminals even its stand Wattage is less than 1 W.
內部損失電阻 (Internal Stray Resistance)
- 0.3 ohm max.
電源供應 (Power Supply)
- None
操作溫度 (Operating Temp.)
- 0 ℃ to 50 ℃ ( 32 ℉ to 122 ℉ ).
操作溼度 (Operating Humidity)
- Less than 80% RH.
體積 (Dimensions)
- HWD 14.7 cm x 11.7 cm x 5.5 cm. ( 5.79 x 4.61 x 2.16 inch ).
重量 (Weight)
- 320 g/0.70 lb.
附件 (Accessories Included)
- Operation Manual.................1 PC.
選購附件 (Optional Accessories)
- Test alligator clips, one pair, TL-05
|
