TM-939
多功能紅外線測溫計
(停產)
特色
- 測量範圍 : IR : -20 ~ 650°C
- 可外接熱電偶測棒 K/J/T/E/R
- 放射率設定 : 0.20 ~ 1.00
- 精確度 : ±3%或3°C,熱電偶±2%
- 距離與量測點比(D:S)=7:1
- 可記錄最大值'最小值及讀值鎖定
- 具有雷射瞄準光點
- RS-232 / USB 連接介面(軟體選購)
- Size:220 X 68 X 30mm
FEATURES
- -20 ℃ to 650 ℃ Wide range IR temperature measurement.
- Infrared thermometer, non-contact temperature measurement, -20 ℃ to 650 ℃ ( -4 ℉ to 1202 ℉ ), precision for none contact temperature measurement.
- Emissivity adjustment for IR thermometer.
- Laser guide for IR thermometer.
- 2 in 1, Infrared thermometer + Thermocouple ( Type K/J/T/E/R ) thermometer.(TM-939)
- Thermocouple probe accepts 5 different types : type K, type J, type T, type E, type R.(TM-939)
- Microcomputer circuit with high performance.
- Build in ℃ & ℉ select button on the front panel.
- Data hold function for stored the desired value on display.
- Memory function to record the maximum & minimum reading with recall.
- Build the REL button, useful for relative measurement.
- Sensor select button on the front panel, easy to change different type probe.(TM-939)
- RS 232 data output, easy cooperate with computer.
- Optional data acquisition software for data record.
- Auto power shut off saves battery life.
- Built-in low battery indicator.
- Heavy duty & compact housing case with stand.
- 006P DC 9V battery poer supply.
一般規格
顯示 (Display)
- 51 mm x 32 mm supper large LCD display, 15 mm ( 0.6" ) digit size.
感應器型式 (Sensor Type)
- 1. Infrared thermometer ( Non contact temperature measurement )
- 2. Thermocouple probe, type K/J/T/E/R
功能 (Functions)
- ℃, ℉, Data hold, Memory ( Max., Min. ), Relative measurement, Emissivity adjustment (IR thermometer).
解析度 (Resolution)
- 1 degree or 0.1 degree.
電路 (Circuit)
- Exclusive microcomputer circuit, the software build in linearity correction instead the traditional hardware circuit.
紅外線感應器 (IR Sensor)
- Thermocouple pie.
紅外線測量波長區域 (IR Measurement Wave length Region)
- 6 to 12 micro meter.
紅外線距離因素 (IR Distance Factor)
- D/S : Approx. 7:1. (D - Distance, S - Spot.)
雷射規範 (Laser Guide)
- Red laser light, less than 1 mW, Meet EN60825
感溫棒輸入接頭 (Probe Input Socket)
- Thermocouple probe :
Standard 2 pin thermocouple socket.
取樣時間 (Sampling Time)
- Approx. 1 second.
鎖定功能 (Hold Function)
- To freeze the display reading value.
記憶回叫 (Memory Recall)
- Memorize the Maximum, Minimum reading with recall.
差距值調整 (Offset Adjustment)
- Available for thermocouple thermometer offset adjustment by pushing button on front panel.
過載指示 (Over Indication)
- Show " - - - - ".
資料輸出 (Data Output)
- RS232 PC serial interface.
電源供應 (Power Supply)
- Alkaline or heavy duty type, DC 9V battery, 006P, MN1604 ( PP3 ) or equivalent.
電源損耗 (Power Consumption)
- Approx. DC 10 mA ( laser guide off ).
- Approx. DC 19 mA ( with laser light on ).
- * Above consumption value is calculated under the function of IR thermometer.
操作溫度 (Operating Temp. )
- 0 to 50 ℃ (32 to 122 ℉).
操作溼度 (Operating Humidity)
- Less than 80% RH.
重量 (Weight)
- 220 g/0.48 LB.
體積 (Dimension)
- HWD 220 x 68 x 30 mm ( 8.7 x 2.7 x 1.2 inch ).
附件 (Standard Accessory)
- Operational manual..... 1 PC.
選購附件 (Optional Accessory)
- * Temperature probe : TP-01, TP-02A, TP-03, TP-04
- * Carrying case, Model : CA-06, CA-03
- * RS232 cable ; Model : UPCB-02
- * USB cable, Model : USB-01
- * Application software, windows version. ; Model : SW-U801-WIN
測量範圍/解析度 (MEASURING RANGE/ RESOLUTION)
Type |
Resolution |
Range |
Accuracy |
Infrared thermometer |
1 ℃ |
- 20 ℃ to 650 ℃ |
-20℃ to 400℃ : ± 3% of reading or ± 3℃ ( 5℉ ) > 400 ℃ : ± 3% of reading |
1 ℉ |
-4 ℉ to 1202 ℉ |
Thermocouple type K |
0.1 ℃ |
-100.0 to -50.0 ℃ |
± (0.2%+1℃) |
0.1 ℃ |
-49.9 to 1300.0 ℃ |
± (0.2%+0.5℃) |
0.1 ℉ |
-148.0 to -58.0 ℉ |
± (0.2%+1.8℉) |
0.1 ℉ |
-57.9 to 2372.0 ℉ |
± (0.2%+1℉) |
Thermocouple type J |
0.1 ℃ |
-100.0 to -50.0 ℃ |
± (0.2%+1℃) |
0.1 ℃ |
-49.9 to 1150.0 ℃ |
± (0.2%+0.5℃) |
0.1 ℉ |
-148.0 to -58.0 ℉ |
± (0.2%+1.8℉) |
0.1 ℉ |
-57.9 to 2102.0 ℉ |
± (0.2%+1℉) |
Thermocouple type T |
0.1 ℃ |
-100.0 to -50.0 ℃ |
± (0.2%+1℃) |
0.1 ℃ |
-49.9 to 400.0 ℃ |
± (0.2%+0.5℃) |
0.1 ℉ |
-148.0 to -58.0 ℉ |
± (0.2%+1.8℉) |
0.1 ℉ |
-57.9 to 752.0 ℉ |
± (0.2%+1℉) |
Thermocouple type E |
0.1 ℃ |
-100.0 to -50.0 ℃ |
± (0.2%+1.3℃) |
0.1 ℃ |
-49.9 to 900.0 ℃ |
± (0.2%+0.8℃) |
0.1 ℉ |
-148.0 to -58.0 ℉ |
± (0.2%+2.8℉) |
0.1 ℉ |
-57.9 to 1652.0 ℉ |
± (0.2%+2℉) |
Thermocouple type R |
1 ℃ |
0 to 600 ℃ |
± (1 %+5℃) |
1 ℃ |
601 to 1700 ℃ |
± (1.5%+5℃) |
1 ℉ |
32 to 1112 ℉ |
± (1 %+10℉) |
1 ℉ |
1113 to 3092 ℉ |
± (1.5 %+10℉) |
選購測溫棒及其他附件 (OPTIONAL
TEMPERATURE PROBE & OTHER ACCESSORIES)
Carrying Case, CA-06
- Model : CA-06, Hard carrying case
Carrying Case, CA-03
- Model : CA-03, Vinyl soft carrying case.
Thermocouple Probe ( Type K ) TP-01
- Measure Rage :
-40 ℃ to 250 ℃, -40 ℉ to 482 ℉.
- Ultra fast response naked-bead thermocouple, general purpose application.
Thermocouple Probe ( Type K ), TP-02A
- Measure Range : -50 ℃ to 900 ℃, -50 ℉ to 1650 ℉.
- Dimension:
10 cm tube, 3.2 mm Dia.
Thermocouple Probe ( Type K ), TP-03
- Measure Range :
-50 ℃ to 1200 ℃, -50 ℉ to 2200 ℉.
- Dimension:
10 cm tube, 8 mm Dia.
Surface Probe ( Type K ), TP-04
- Measure Range : -50 ℃ to 400 ℃, -50 ℉ to 752 ℉.
- Size : Temp. sensing head - 15 mm Dia. Probe length - 120 mm.
RS232 cable, UPCB-02
- RS232 cable for connecting between the meter & the computer.
Application Software, SW-U801-WIN
- Windows software apply as the performance of data logging system & data recorder...
|
