SL-406
噪音轉換器
(停產)
特色
- 測量範圍 :
- 35 ~ 80 (分貝)
- 50 ~ 100 (分貝)
- 80 ~ 130dB (分貝)
- 輸出 : 1mV=1dB A/C加權網路測量選擇(dBA)
- 響應頻率範圍 : 31.5 ~ 8000HZ
- 精確度 : ±1.5dB (94dB/1KHz)
- 符合國際規範IEC651Type2
- Size : 107 x 53 x 29mm.
FEATURES
- Cooperate with the DMM to be as a professional sound level meter.
- 35 to 130 dB, 3 ranges.
- Frequency weighting networks are designed to meet the IEC 61672 class 2.
- A weighting networks are conformity to standards.
- Fast Time weighting dynamic characteristic modes.
- Condenser microphone for high accuracy & long-term stability.
- Over/Under indicator.
- Low battery indicator.
- Frequency 31.5 Hz to 8,000 Hz.
- Electric condenser microphone.
- Size of microphone : 1/2 inch standard size.
規格
測量/範圍 (Measurement/Range)
- 30 to 130 dB, 3 ranges
- Range 1 : 30 to 80 dB.
- Range 2 : 50 to 100 dB.
- Range 3 : 80 to 130 dB.
輸出 (Output )
- 10 mV per 1 dB.
精確度 (Accuracy )(23 5 ℃)
- Frequency weighting meet IEC 61672 class 2, calibrating input signal on 94 dB ( 31.5 Hz to 8 kHz ), then the accuracy of A weighting is specified as following :
- 31.5 Hz: ± 3.5 dB
- 63 Hz:± 2.5 dB
- 125 Hz:± 2.0 dB
- 250 Hz:± 1.9 dB
- 500 Hz:± 1.9 dB
- 1 kHz:± 1.4 dB
- 2 kHz:± 2.6 dB
- 4 kHz:± 3.6 dB
- 8 kHz:± 5.6 dB
頻率加權迴路 (Frequency Weighting Network )
- Characteristics of A weighting.
- A weighting : The characteristic is simulated as "Human Ear Listing" response.
頻率 (Frequency )
- 31.5 Hz to 8,000 Hz.
校正器 (Calibrator )
- B & K (Bruel & Kjaer) : Multi-fuction acoustic calibrator, Model : 4226.
麥克風型態 (Microphone type)
- Electric condenser microphone.
麥克風大小 (Size of microphone)
- 1/2 inch standard size.
校正 VR (Calibration VR)
- Build in external calibration VR.
電池 (Battery)
- DC 9 V battery (006P, 6F22).
電源消耗 (Power Consumption)
- Approx. DC 4 mA.
操作溫度 (Operating Temperature)
- 0 ℃ to 50 ℃ (32 ℉ to 122 ℉).
操作溼度(Operating Humidity)
- Less than 80% RH.
重量 (Weight)
- 150g g/0.33 LB (including battery).
體積(Dimension)
- Main instrument : 107 x 53 x 29 mm ( 4.2 x 2.1 x 1.1 inch ).
- Probe : Dia. 12.7 mm x 58 mm ( Dia. 0.5 inch x 2.28 inch).
附件 (Accessories Included)
- Operation Manual..............1 PC.
選購校正器及附件 (Optional Calibrator, Accessory)
- 94 dB Sound Calibrator, Model : SC-941.
- 94/114 dB Sound Calibrator, Model : SC-942.
- Wind shield ball, Model : SB-01
|
