TM-949
多功能紅外線測溫計
(停產)
特色
- 測量範圍 : IR : -20 ~ 650°C
- 放射率設定 : 0.20 ~ 1.00
- 精確度 : ±3%或3°C,熱電偶±2%
- 距離與量測點比(D:S)=7:1
- 可記錄最大值'最小值及讀值鎖定
- 具有雷射瞄準光點
- RS-232 / USB 連接介面(軟體選購)
- Size：220 X 68 X 30mm
FEATURES
- -20 ℃ to 650 ℃ Wide range IR temperature measurement.
- Infrared thermometer, non-contact temperature measurement, -20 ℃ to 650 ℃ ( -4 ℉ to 1202 ℉ ), precision for none contact temperature measurement.
- Emissivity adjustment for IR thermometer.
- Laser guide for IR thermometer.
- Microcomputer circuit with high performance.
- Build in ℃ & ℉ select button on the front panel.
- Data hold function for stored the desired value on display.
- Memory function to record the maximum & minimum reading with recall.
- Build the REL button, useful for relative measurement.
- RS 232 data output, easy cooperate with computer.
- Optional data acquisition software for data record.
- Auto power shut off saves battery life.
- Built-in low battery indicator.
- Heavy duty & compact housing case with stand.
- 006P DC 9V battery poer supply.
一般規格
顯示 (Display)
- 51 mm x 32 mm supper large LCD display, 15 mm ( 0.6" ) digit size.
感應器型式 (Sensor Type)
- 1. Infrared thermometer ( Non contact temperature measurement )
功能 (Functions)
- ℃, ℉, Data hold, Memory ( Max., Min. ), Relative measurement, Emissivity adjustment (IR thermometer).
解析度 (Resolution)
- 1 degree or 0.1 degree.
電路 (Circuit)
- Exclusive microcomputer circuit, the software build in linearity correction instead the traditional hardware circuit.
紅外線感應器 (IR Sensor)
- Thermocouple pie.
紅外線測量波長區域 (IR Measurement Wave length Region)
- 6 to 12 micro meter.
紅外線距離因素 (IR Distance Factor)
- D/S : Approx. 7:1. (D - Distance, S - Spot.)
雷射規範 (Laser Guide)
- Red laser light, less than 1 mW, Meet EN60825
感溫棒輸入接頭 (Probe Input Socket)
- Thermocouple probe :
Standard 2 pin thermocouple socket.
取樣時間 (Sampling Time)
- Approx. 1 second.
鎖定功能 (Hold Function)
- To freeze the display reading value.
記憶回叫 (Memory Recall)
- Memorize the Maximum, Minimum reading with recall.
差距值調整 (Offset Adjustment)
- Available for thermocouple thermometer offset adjustment by pushing button on front panel.
過載指示 (Over Indication)
- Show " - - - - ".
資料輸出 (Data Output)
- RS232 PC serial interface.
電源供應 (Power Supply)
- Alkaline or heavy duty type, DC 9V battery, 006P, MN1604 ( PP3 ) or equivalent.
電源損耗 (Power Consumption)
- Approx. DC 10 mA ( laser guide off ).
- Approx. DC 19 mA ( with laser light on ).
- * Above consumption value is calculated under the function of IR thermometer.
操作溫度 (Operating Temp. )
- 0 to 50 ℃ (32 to 122 ℉).
操作溼度 (Operating Humidity)
- Less than 80% RH.
重量 (Weight)
- 220 g/0.48 LB.
體積 (Dimension)
- HWD 220 x 68 x 30 mm ( 8.7 x 2.7 x 1.2 inch ).
附件 (Standard Accessory)
- Operational manual..... 1 PC.
選購附件 (Optional Accessory)
- * Carrying case, Model : CA-06, CA-03
- * RS232 cable ; Model : UPCB-02
- * USB cable, Model : USB-01
- * Application software, windows version. ; Model : SW-U801-WIN
選購測溫棒及其他附件 (OPTIONAL TEMPERATURE PROBE & OTHER ACCESSORIES)
Carrying Case, CA-06
- Model : CA-06, Hard carrying case
Carrying Case, CA-03
- Model : CA-03, Vinyl soft carrying case.
RS232 cable, UPCB-02
- RS232 cable for connecting between the meter & the computer.
Application Software, SW-U801-WIN
- Windows software apply as the performance of data logging system & data recorder...
|
