DM-9982G
綠能智慧型電錶
簡介
- 可由手搖發電機提供電源，亦可使用電池
- 手搖發電機 10秒以上，可提供短暫待測電量
- 交直流電壓 (AC / DC)：0.001 ~ 600.0V
- 電阻：0.1 ~ 6MΩ
- 電容：0.001nF ~ 60.00uF
- 二極體、導通蜂鳴測試
- 電壓、電阻自動換檔
- 交直流電壓自動判別，免切換
- Size：152 X 78 X 45mm
FEATURES
- Green power, battery is no need, power supply from the handy generator, operate the generator 10 to 20 seconds will offer 10 minutes energy typically.
- Hybrid power, meter also can supply by the battery.
- Meet CAT III-600 V.
- 6000 counts A/D, high resolution.
- ACV, DCV, ohms, continuity, Capacitance, Diode.
- Smart function and auto range.
- Smart operation, Build in 2 intelligent function : " V ", " Ω "." V " function can select ACV, DCV automatically with auto range.
- " Ω " function can select the Resistance , Diode, Continuity beeper, Capacitance automatically with auto range.
- Manual power off or auto power off.
- Auto shut off is available to save battery life.
- 10M ohm impedance for voltage circuit.
- Built-in overload protection for all range.
- LSI circuit provides high reliability and durability.
- Patent.
- Uses durable, long-lasting components, enclosed in strong, light weight ABS-plastic housing.
- DIY version , easy operation.
一般規格
綠色及混合電源 (Green power and Hybrid powe)
- Green power, battery is no need, power supply from the handy generator, operate 10 to 20 seconds the generator will offer 10 minutes energy typically.
-
- Hybrid power, meter also can supply by the battery power
顯示 (Display)
- 46 mm x 45 mm large LCD display.
測量 (Measurement)
- ACV, DCV , ohms, continuity beeper, Hz, Capacitance, Diode.
A/D 計數次數 (A/D counts no.)
- 6000 counts.
範圍選擇 (Range selection)
- Smart function , auto range.
時尚功能 (Smart function)
- " V " function can select ACV, DCV automatically with auto range.
- " Ω " function can select the Resistance, Diode, Continuity beeper, Capacitance Diode, Continuity beeper, Capacitance
電源開/關機管理 (Power On/Off management)
- Manual power off.Auto power off : If meter is not operated within 3 minutes will auto power switch off.
極性 (Polarity)
- Automatic Switching, "－ " indicates negative polarity.
歸零調整 (Zero adjustment)
- Automatic.
取樣時間 (Sampling time)
- Approx. 0.5 to 1 second.
操作溫度 (Operating Temperature)
- 0 to 50 ℃ (32 to 122 ℉).
操作溼度 (Operating Humidity)
- Less than 80% RH.
電源供應 (Power Supply)
- Power from the handy generator, battery is no need.
- Battery power : DC3V battery ( CR-2032 ) x 2 PCs.
電源消耗 (Power Consumption)
- Approx. DC 3 mA.
體積 (Dimensions)
- 152 x 78 x 45 mm ( 6.0 x 3.1 x 1.8 inch ).
重量 (Weight)
- 320 g/0.70 LB.
附件 (Accessories Included)
- Red and Black Test Leads ..... 1 pair.
- Instruction Manual ........... 1 PC.
電器規格 (23±5 ℃)
直流/交流電壓 (DC/AC Voltage) 自動換檔(auto range)
- Range : 6V/ 60V/ 600V
- Resolution : 0.001V/ 0.01V/ 0.1V
- Accuracy :
- DCV : ± ( 1 % + 2d )
- ACV : ± ( 1.2 % + 5d )
- Input impedance : 10M ohm.
- Over load protection : AC/DC 600V.
Remark
- * The input impedance is 10 Mega ohm.
- * ACV specification be tested on sine wave 50/60 Hz.
- * The ACV start measurement voltage is larger than 400mV ± 100mV.
歐姆 (OHMS) 自動換檔(auto range)
- Range : 600/ 6K/ 60K/ 600K/ 6M ohm
- Resolution : 0.1/ 1/ 10/ 100/ 1K ohm
- Accuracy : ± ( 1% + 3d )
- Over load protection : ± 350 DCV , 350 ACV
電容 (Capacitance) 自動換檔(auto range)
- Range : 6nF/ 60nF/ 600nF/ 6uF/ 60uF
- Resolution : 0.001nF/ 0.01nF/ 0.1nF/ 0.001uF/ 0.01uF
- Accuracy : ± ( 3% + 5d )
- Remark : Discharge capacitor before testing.
二極體 (Diode)
- Short/non conductance, good/defect test.
導通測試 (Continuity)
- If measuring resistance is less than 10 ohm, the beeper will sound .
|
