DM-9030
汽車引擎轉速表
簡介
-
引擎轉速：500 ~ 10000RPM
±1.2%
-
交直流電壓：0 ~ 600V
±0.8%
-
交直流電流：0 ~ 10A
±1.5%
-
電阻：0 ~ 20M歐姆
±0.8%
-
頻率：0.1Hz ~ 20KHz
±1%
-
溫度：-20ºC ~ 750ºC
(0 ~ 1400°F) ±1%
-
白金閉角. % (百分比)測量
-
Size：185
X 87 X 39mm
FEATURES
- Multi function measurement. DCV ,
ACV , DCA , ACA , OHMS , TEMPERATURE , Hz , RPM , DWELL ANGLE , DIODE ,
CONTINUITY BEEPER.
- RPM (TACH) measurement by
inductive pickup for more convenient & accurate readings of both
conventional and distributorless ignitions.
- RPM (TACH) used the " Secondary
Tach. " measuring method, no matter what cylinder no is.
- Accurate DCV / ACV, DCA / ACA and
resistance measurement, wide range of automotive electronics tests.
- Duty cycle (%) with Dwell
conversion chart for electronic fuel injection and feedback
carburetors.
- Diode test quickly measures the
forward bias voltage drop of alternator rectifiers and other diodes.
- Continuity beeper keeps whenever
probes touch a continuous circuit. Helps find shorts and open wires.
- 10 Mega ohm impedance protects
Mega ohm computer circuit.
- Frequency measurements with
adjustable trigger point for testing MAF, MAP & ABS SENSOR.
- Rotary function switch, easy
operation.
- Large size LCD display.
- Built-in overload protection for
most ranges.
一般規格
顯示 (Display)
- 18 mm ( 0.7" ) LCD,
3½
digits,
Max. indication 999.
測量 (Measurement)
- 36 ranges covering : DCV , ACV , DCA ,
ACA , OHMS , TEMPERATURE , Hz , RPM , DWELL ANGLE , DIODE , CONTINUITY
BEEPER.
極性 (Polarity)
- Automatic Switching , ' － ' indicates
negative polarity.
歸零調整 (Zero Adjustment)
- Automatic adjustment.
過載輸入顯示
(Over-input)
- Display shows " 1 " or " -1 ".
取樣時間 (Sampling
Time)
- Approx. 0.4 second.
操作溫度 (Operating Temp.)
- 0 ℃ to 50 ℃ ( 32 ℉ to 122 ℉ ).
操作溼度 (Operating
Humidity)
- Less than 80% RH.
體積 (Dimensions)
- 185 x 87 x 39 mm( 7.3 x 3.4 x 1.5
inch )
重量 (Weight)
- 322 g / 0.71 LB ( including battery ).
電源消耗 (Power Consumption)
- Approx. DC 3.6 mA.
附件 (Accessories
Included)
- Red and Black Test
leads............................... 1 pair
- Instruction Manual
................. 1 PC.
選購附件
- RPM inductive pick up sensor
( IP-07, IP-09 )
- Temperature probe, carrying
case...
電器規格 (23±5 ℃)
直流電壓 (DC Voltage)
|
RANGE |
ACCURACY |
RESOLUTION |
INPUT IMPEDANCE |
OVERLOAD
PROTECTION |
|
200mV |
± (0.5%+1d) |
100uV |
10M
ohm |
500V DC, 350V
AC, 15 secs |
|
2V |
±
(0.8%+1d) |
1mV |
DC
600V AC 600V |
|
20V |
10mV |
|
200V |
100mV |
|
600V |
1V |
交流電壓 (AC Voltage) *
FREQUENCY RESPONSE: 40Hz-500Hz, SINE WAVE SPEC. TESTED ON 60Hz/50Hz
|
RANGE |
ACCURACY |
RESOLUTION |
INPUT IMPEDANCE |
OVERLOAD
PROTECTION |
|
200mV |
± (
1%+2d) |
100uV |
10M
ohm |
500V DC, 350V
AC, 15 secs |
|
2V |
1mV |
DC
600V AC 600V |
|
20V |
10mV |
|
200V |
100mV |
|
600V |
1V |
交/直流電流 (AC/DC Current)
* FREQUENCY RESPONSE: 40Hz-500Hz, SINE WAVE SPEC. TESTED ON 60Hz/50Hz
|
RANGE |
ACCURACY |
RESOLUTION |
VOLTAGE DROP |
OVERLOAD PROTECTION |
|
10A |
DCA:± (1.5%+2d)
ACA:± (1.5%+3d) |
10mA |
ACA:AC200mV
DCA:DC200mV |
10A UNFUSED |
電阻 (RESISTANCE)
|
RANGE |
ACCURACY |
RESOLUTION |
OPEN CKT. VOLTAGE |
OVERLOAD
PROTECTION |
|
200 ohm |
± (1%+3d) |
0.1 ohm |
3 V Max. |
AC
500V ( Protected by PTC ) |
|
2K |
±
(0.8%+1d) |
1 ohm |
APPROX. 0.3 V Max. |
|
20K |
10 ohm |
|
200K |
100 ohm |
|
2000K |
1K ohm |
|
20M |
± (2%+2d) |
10K ohm |
白金閉角 (DWELL)
|
CYLINDER |
RANGE |
RESOLUTION |
ACCURACY |
OVERLOAD
PROTECTION |
|
3 CYL |
0 - 120 |
0.1
degree |
±
(1.2%+1d) |
200V DC/AC RMS
(within 15
sec) |
|
4 CYL |
0 - 90 |
|
5 CYL |
0 - 72 |
|
6 CYL |
0 - 60 |
|
8 CYL |
0 - 45 |
|
DUTY CYCLE |
0 - 100.0 % |
0.1 % |
引擎轉速 (TACH)
Secondary tach. , no matter what cyl. no. is
|
RANGE |
ACCURACY |
RESOLUTION |
VOLTAGE DROP |
|
500 - 10,000
RPM |
10 RPM |
± (1.2%+1d) |
24V DC/AC RMS
(within 1 min.) |
溫度 (TEMPERATURE)
|
RANGE |
RESOLUTION |
ACCURACY |
|
-20℃ to 750℃ |
1℃ |
>0℃, ± (1% +
2dgt) To 300 ℃, (Over 550℉ 3%) |
|
0℉ to 1400℉ |
1℉ |
>32℉,± ( 1% +
3dgt) To 550 ℉, (Over 500 ℉ 3%) |
頻率 (FREQUENCY (Hz))
|
RANGE |
MEASURING RANGE |
ACCURACY |
RESOLUTION |
INPUT SENSITIVITY
|
MAX. INPUT VOLTAGE |
|
200Hz |
9-199.9 Hz
9-1999 Hz
0.9-19.99 kHz |
±(1%+ 2d) |
0.1 Hz |
35mV RMS |
500V DC/AC |
|
2 KHz |
1Hz |
|
20KHz |
10Hz |
導通蜂鳴測試 (CONTINUITY
BEEPER)
A CONTINUITY TEST BEEPER IS STANDARD.
SO WHEN ARE CHECKING CIRCUITS FOR SHORTS OR OPENS, YOU DO NOT HAVE TO
LOOK AT THE METER. THE BEEPER SOUNDS IF CONTINUITY IS PRESENT.
二極體 (Diode TEST)
- Open circuit voltage is approx. DC
3V max.
選購轉換器
(OPTIONAL ADAPTER) (OP ADPT.)
|
RANGE |
MAX. DISPLAY
CAPACITY |
PER DIGIT EQUAL: |
ACCURACY |
|
EXT ADPT |
2000 x 1 |
0.1 mV DC |
±
(1.2% + 2d) |
|
200 A |
200.0 x 0.1 |
0.1 mV DC |
|
2000 A |
2000 x 1 |
1 mV DC |
|
BATT TEST |
200.0 x 0.1 |
0.1 V DC |
選購溫度感測棒及其他配備
Full line adapters :1000 A, 2000
A ACA/DAC current adapter, Tachometer adapter, IR adapter, Humidity
adapter, Pressure adapter, Light adapter, EMF adapter, Sound adapter,
High voltage probe...
Temp. probe : Type K, TP-01,
TP-02A, TP-03, TP-04.
RPM inductive pick up sensor :
IP-07, IP09
Carrying case :Soft
carrying case. Size : 190 x 90 x 55
mm.......CA-03
Soft carrying case with sash. Size : 260 x 110 x 55
mm............ CA-05A
|
