CC-420
電壓/電流校正器
(停產)
特色
- 具有校正及測量功能
- 可調式輸出信號 : 0 ~ 24.0mA
- 測量輸入範圍 : 0 ~ 24.0mA
- 提供DC12V電壓/兩線式電流迴路測試
- 外觀採摺合式設計,攜帶方便
- Size:96 X 108 X 45mm
FEATURES
- Precision meter for calibrating process devices and measuring process signals.
- Adjustable 0-24 mA source for calibrating current devices .
- Calibrator drives loads to 500 ohms.
- Power or Measure a two-wire current loop
- Display resolution to 0.01 mA or 0.1 mA or 0.1%.
- High accuracy 0.025%.
- Oyster case with "flip-up" display is ideal for handheld or bench top applications .
- Three modes provide the quality and accuracy of bench top calibrator : precision current source; measurement of a current signal: power and measurement of two wire transmitters. The large LCD can display readings in mA (to 0.01 mA) or as a percentage of the 0-24 mA range (4-20 mA = 0-100.0%).
- Precision readings and rugged design of the unique Oyster series case makes this the ideal portable calibrator for process applications, manufacturing, product design, or laboratory facilities. when the lid is closed, the power is automatically shut off and the LCD is protected.
規格
操作模式 (Operating modes)
- Source : output 0-24 mA current for loads up to 500 ohms.
- Measure : 0-24 mA current signal
- Power/Measure : Provides power (12 VDC) to the loop and measures current
輸出/入範圍及顯示 (Input/output ranges and display)
- -25.0 to 125.0% (representing 0 to 24 mA)
- 0 to 19.99 mA
- 0 to 24.0 mA
解析度 (Resolution)
- 0.01 mA (0 to 19.99 mA)
- 0.1 mA (0 to 24.0 mA)
- 0.1% (-25 to 125.0%)
精確度 (Accuracy)
- ± ( 0.025% +1 d ).
電源 (Power)
- 006P 9 volt battery or AC adapter ( optional ) .
重量 (Weight)
- Approx. 340 g (0.75 LB).
體積 (Dimension)
- 96 x 108 x 45 mm ( 3.8 x 4.2 x 1.8 inch ).
附件 (Accessories included)
- Test leads terminated with spade lugs......... 1 PC
- Operational manual............................ 1 PC.
|
