PH-209G
綠能酸鹼計
(停產)
特色
- 可由手搖發電機提供電源,亦可使用電池
- 手搖發電機10秒以上,可提供短暫待測電量
- 測量範圍 :
- 酸鹼度: 0 ~ 14.00 PH ±0.02PH
- 氧化還原: -1000mV ~ +1000mV ±0.5%
- 手動溫度補償 : 0 ~ 100.0°C
- 自動溫度補償 : 0 ~ 65.0°C
- 校正調整 : PH4 (斜率調整) , PH7 (零點調整)
- 雙視窗同時顯示PH值及溫度
- 可記錄最大值,最小值及讀值鎖定
- RS-232 / USB 輸出介面 (軟體選購)
- Size : 170 x 70 x 39mm
FEATURES
- Hybrid power, power supply from green power ( handy generator ) or battery. If power source come from " Green power ", battery is no need. Operate the generator 20 seconds will offer 10 minutes energy typically.
- Professional pH/mV METER.
pH range : 0 to 14 pH mV range : -1000 mV to 1000 mV.
- The instrument is with mV ( millivolt ) function for mV measurement ( cooperate with optional ORP probe to be a professional ORP meter)
- Wide range manual temperature compensation adjustment .
- Optional ATC (Automatic Temp. Compensation) probe is available for pH measurement.
- Internal Temp. unit ℃ or ℉ selection.
- pH function with high input impedance avoids measuring error.
- Microprocessor circuit assures high accuracy and reliable performance.
- Large LCD, dual function display.
- Records Maximum and Minimum readings with recall.
- Data hold.
- Auto power shut off to battery life or manual power off.
- Powered by 006P DC 9V battery.
- RS 232/USB computer serial interface.
- Easy and automatic pH calibration procedures.
- Using the durable, long-lasting components and a strong lightweight ABS-plastic housing case.
- Wide applications:
water conditioning, aquariums, beverage, fish hatcheries, food processing, photography, laboratory, paper industry, plating industry, quality control, school & college.
一般規格
電路 (Circuit)
- Custom one-chip of microprocessor LSI circuit.
顯示 (Display)
- 40 mm x 32 mm LCD (Liquid crystal display).
測量 (Measurement)
- pH : 0 to 14 pH.
- mV: -1000 mV to 1000 mV
輸入阻抗 (Input Impedance)
- 10^12 ohms
溫度補償 (pH Temp. Compensation)
- Manual 0 to 100 ℃, be adjusted by push button on front panel.
- Automatic ( ATC ) * Cooperate the optional Temp. probe, TP-07. ; * 0 to 65 ℃.
pH 校正 (pH Calibration)
- pH 7, pH 4 or pH 10, 3 points calibration ensure the best linearity and accuracy.
資料鎖定 (Data hold)
- Hold the current reading value on the display
記憶回叫 (Memory Recall)
- Maximum and Minimum reading values can be saved and retrieved by record function.
取樣時間 (Sampling Time)
- Approx. 1 sec
關機 (Power off)
- Auto shut off saves battery life, or manual off by push button.
資料輸出 (Data Output)
- RS 232/USB PC computer interface.
- * Connect the optional RS232 cable UPCB-02 will get the RS232 plug (D9 plug ).
- * Connect the optional USB cable USB-01 will get the USB plug.
過載指示 (Overload indication)
- "- - - -" symbol on the display.
PH電極 (pH electrode) Optional
- Optional, Any connector PH Electrode with BNC connector.
操作溫度 (Operating Temp. )
- 0 ℃ to 50 ℃(32 ℉ to 122 ℉).
操作溼度 (Operating Humidity)
- Max. 80% RH.
電源供應 (Power Supply) Hybrid power
- Green power : Power from the handy generator, battery is no need.
- Battery power :
DC 9V battery, 006P, MN1604 ( PP3 ) or equivalent.
- * Alkaline or heavy duty type.
電源損耗 (Power Consumption)
- Battery power : Approx. DC 4.5 mA.
重量 (Weight)
- 362 g/0.8 LB ( battery included ).
體積 (Dimension)
- 170 x 70 x 39 mm ( 6.7 x 2.8 x 1.1.5 inch).
附件 (Standard Accessory)
- Instruction Manual............................................. 1 PC
選購附件 (Optional accessories)
- pH electrodes :
- * General purpose pH electrode, PE-03.
- * General purpose pH electrode, PE-11.
- * Professional pH electrode, PE-01.
- * Spear tip pH electrode : PE-06HD, PE-04HD
- * pH electrode build in Temp. sensor, PE-05T
- * pH electrode + Temp. probe, kit, PE-03K7
- ORP electrode : ORP-14
- Hard carrying case, CA-06
- Soft carrying case, CA-05A
- RS232 cable, UPCB-02
- USB cable, USB-01
- Data acquisition software (Windows version ), SW-U801-WIN
電器規格 ELECTRICAL SPECIFICATIONS (23 ±5℃)
Measurement |
Measuring Range |
Resolution |
Accuracy |
pH |
0 to 14 pH |
0.01 pH |
± (0.02 pH + 2 d) * Meter only |
mV |
0 to ± 1000 mV |
1 mV |
± (0.5% + 2 d) * Meter only |
* pH accuracy is based on calibrated meter only.
* Specification tests under the environment RF Field Strength less than 3 V/M & frequency less than 30 MHz only.
|
