DM-6055C
多功能交直流鉤錶
簡介
- 交直流電壓：0.1V ~ 600V ±0.8%
- 交直流電流：0.1A ~ 1000A ±1.5%
- 電阻：0 ~ 2000歐姆 ±1%
- 溫度：-40ºC ~ 750ºC ±1%
- 讀值鎖定’峰值鎖定功能
- 鉤部口徑 32mm
- Size：230 X 70 X 36mm
FEATURES
- Measure max. 1000 A DCA or ACA by the inductive conductor, contactless.
- Design meet IEC 1010 safety requirement.
- Multi-functions for ACA , DCA , ACV , DCV , ohms , Diode , Temperature.
- Built-in Data Hold function.
- Built-in Peak Hold function for measuring transient signal.
- LCD display, easy & clear readout.
- High internal impedance, assures min. measuring error.
- LSI-circuit provides high reliability and durability.
- Built-in low battery indicator.
- Overload protection circuit is provided for all range.
- Compact & heavy duty ABS housing plastic case.
一般規格
顯示 (Display)
- 13 mm (0.5") LCD , 3 1/2 digits. Max. indication 1999.
測量範圍 (Measurement Range)
- ACA, DCA, ACV, DCV, Ohms, Data hold, Peak Hold, Temperature.
極性 (Polarity)
- Automatic Switching, ' － ' indicates negative polarity.
電流感應器 (Current Sensor)
- Hall effect sensors.
歸零調整 (Zero Adjustment)
- DCA : External knob, for DCA zero
- Other : Automatic adjustment.
輸入過載指示 (Over-input indicator)
- Indication of ' 1 ' or ' -1 '.
取樣時間 (Sampling Time)
- Approx. 0.4 second.
電池 (Battery)
- DC 9V battery, heavy duty or Alkaline type, 006P, MN1604 ( PP3 ) or equivalent.
電源消耗 (Power Consumption)
- Approx. DC 11 mA.
操作溫度 (Operating Temp.)
- 0 ℃ to 50 ℃ ( 32 ℉ to 122 ℉ ).
操作溼度 (Operating Humidity)
- Less than 80% RH.
重量 (Weight)
- 400 g/0.90 LB ( including battery ).
體積 (Dimensions)
- HWD 230 x 70 x 36 mm ( 9.1 x 2.8 x 1.4 inch )
鉤部口徑 (Conductor Jaw Size)
- 78.5 mm ( 3.1 inch ) - outside
附件 (Accessories Included)
- Red and Black Test Leads .......... 1 pair.
- Operation manual................... 1 PC.
- Carrying case ......................1 PC.
- TP-01 Thermocouple probe with plug..1 PC.
電器規格 (23±5 ℃)
| Function |
Range |
Resolution |
Accuracy |
Overload Protection | Remark |
| DC Voltage |
200 V |
0.1 V |
± ( 0.8 % + 1 d ) |
AC/DC 600 V. |
Input impedance 10 Mega ohm |
| 600 V |
1 V |
|
AC Voltage ( 50/60Hz ) |
200 V |
0.1 V |
± ( 1 % + 2 d ) |
AC/DC 600 V. |
Input impedance 10 Mega ohm |
| 600 V |
1 V |
| Resistance |
2000 ohm |
1 ohm |
± ( 1 % + 1 d ) |
AC/DC 400 V |
|
| AC/DC Current |
200 A |
0.1 A |
± ( 1.5 % + 15 d ) |
AC/DC 1000 A |
ACA Spec. test on 60 Hz/50 Hz. |
| 1000 A |
1 A |
± ( 2 % + 5 d ) |
| Temp. ℃ Model |
-40 ℃ to750 ℃ |
1 ℃ |
0 to 750 ℃ :± ( 1 % + 2 ℃ ) 0 to -20 ℃ : typ.± 2 ℃ -20 to -40 ℃ : typ.± 3 ℃ |
|
|
| Diode Check |
Short/non conductance, good/defect test. Approx. diode VF ( forward voltage ). |
| Peak Hold |
Acquisition Time : 150 ms, Accuracy : 3%, Display Decay Rate : < 2 digits/sec. Application : Use for measuring transient signal for current . |
| Data Hold |
Available for all functions to keep the data hold on the display . |
Remark |
- * Input impedance for ACV & DCV range is 10 Mega ohm.
- * ACA, ACV frequency response is from 40 to 400 Hz.
- * ACA, ACV specification be tested on sine wave 50/60 Hz.
|
type K 測溫棒 ( type K THERMOCOUPLE PROBE)
| TP-01 |
-40 ℃ to 250 ℃ ( 300 ℃ short- term ). Ultra fast response naked-bead probe. |
TP-03 |
-50 ℃ to 1200 ℃ ( -50 ℉ to 2200 ℉ ). High temperature, Penetration & immersion. |
| TP-02A |
-50 ℃ to 900 ℃ ( -50 ℉ to 1650 ℉ ). |
TP-04 |
-50 ℃ to 400 ℃ ( -50 ℉ to 752 ℉ ). |
| Remark : TP-01 is the standard accessory of the DM-6055C, DM-6055F. TP-02A, TP-03, TP-04 are optional |
|
